Product Features

• Functions
• 1. FM radio
• 2. U disk (audio/video/picture)
• 3. BT function
• 4. RCA audio output can be connected to a subwoofer
• 5. Rear view function when reversing
• 6. Video input and output functions
• 7. Original car steering wheel learning function
• 8. Mobile phone interconnection Wired and wireless Android AUTO/ iOS CarPlay
• 9. Colorful lights
• 10. Rear USB
• 11. USB charging port
• 12. Protection function for reverse polarity of the power supply (if the positive and negative poles of the power cord are connected incorrectly, the circuit board will not be burned)
• 13. RDS function, can receive traffic radio stations in real time
• Specifications
• Basic Parameters:
• 1. Type Car: MP5
• 2. System: Allwinner melis system
• 3. Software solution: F133
• 4. Radio frequency: FM 87.5~108.0MHz / 522~1620KHz (the radio frequency can be switched in China, America 1, America 2, Japan, Russia, the Middle East, and Europe)
• 5. Radio IC: 4732
• 6. Power amplifier IC: CD7388CZ
• 7. Output power: 60Wx4
• 8. Working voltage: 12~14.4V
• 9. Working temperature: -10~60 degrees Celsius
• 10. Bluetooth version: version 5.1 (default name: SWL-BT)
• Performance Parameters:
• 1. CPU: F133
• 2. Running memory: 533M
• 3. Display resolution: 800x480
• 4. Screen size: 5 inches
• Dimensions & Weight Parameters:
• 1. Installation size: 178x52mm
• 2. Case size: 188x83mm
• 3. Host depth: 95mm
• 4. Single unit weight: 0.720kg
• Function Parameter:
• 1. Mobile Internet: Supported
• 2. Reversing image: supported (camera optional)
• 3. Play video warning: Support
• 4. Steering wheel control: supports button learning
• 5. Video output: support
• 6. USB: front USB charging + front USB2.0 reading + rear USB2.0 reading
• 7. Reset button: Support
• RCA port Parameters:
• 1. Audio output: 2 channels (left channel + right channel)
• 2. Video output: 2 channels
• 3. Rear external microphone input: supported (external microphone optional)
• 4. Video input: 1 channel
• 5. Reversing video input: 1 channel
• Format Parameters:
• 1. Audio format: MP3/AAC/APE/OGG/M4A/RA/WAV
• 2. Video format: H263/H264/H265/DIVX HD(720P 1080I 1080P)AVI/FLV/MKV/MPEG/MP4/WMV9/VC/ASF/TS/QT
• 3. Image format: JPEG/PNG/BMP/GIF/TIFF
• Language Parameters:
• English, Chinese, French, German, Arabic, Italian, Japanese, Portuguese, Russian, Spanish, Hebrew, Polish, Turkish, Czech
• Other Parameters:
• Factory setting password: 113266
• Package List
• 1. Host x 1
• 2. Instruction x 1
• 3. Power cord x 1
• 4. Remote control x 1
• 5. Vehicle key (Accessories, instructions, and packaging will be updated from time to time, subject to actual receipt of the goods) x 1
