Product Features

• Basic functions
• 1. Radio
• 2. Read USB disk (audio/video/picture)
• 3. Bluetooth function
• 4. Reversing rear view function (camera optional)
• 5. Audio input, video input, video output function
• 6. Original car steering wheel learning function
• 7. Android recorder can be installed (recorder optional)
• 8. WIFI Internet access
• 9. GPS navigation
• 10. APP can be installed
• 11. External microphone (external microphone optional)
• 12. Wired and wireless android auto/Apple carplay function, mirrorlink (Android USB+WIFI, For Apple WIFI)
• 13. Recorder function
• 14. RDS function, can receive traffic radio in real time
• 15. Power supply positive and negative reverse connection protection function (the power line positive and negative poles are connected incorrectly, which will not cause the circuit board to burn)
• Basic parameters:
• 1. System: Android 13
• 2. Software solution: Jinganchi 8227
• 3. Radio frequency: FM 87.5~108.0MHz (switchable to Europe, Eastern Europe, North America, South America, 4. Africa, Australia, Japan regional radio frequency)
• 5. Radio chip: 6625
• 6. Amplifier chip: 7388
• 7. Output power: 60Wx4
• 8. Working voltage: 12~14.4V
• 9. Bluetooth version: version 5.1 (default name: SWL-BT)
• 10. Wi-Fi frequency: 2.4GHz, 5GHz
• 11. GPS signal: Beidou/GPS+GLONASS
• 12. Panel light: None
• 13. CPU: AC8227L Cortex-A7 quad-core processor, main frequency 1.1GHz
• 14. Running memory: 1G, optional 2G
• 15. Storage memory: 16G Optional 32G/64G
• 16. Display resolution: 768x1024 HD
• 17. Screen size: 9.7 inches
• 18. Support mobile phone interconnection, reversing image (camera self-equipped), video playback warning, steering wheel control (support key learning) USB interface (rear USB2.0), driving recorder (USB signal input, recorder self-equipped), reset button
• 19. Language: Chinese/Traditional Chinese/English/Russian/Greek/Polish/Turkish/Arabic/Persian/Romanian/French/Hungarian/Italian/Thai/German/Ukrainian/Spanish/Portuguese/Czech/Vietnamese/Japanese/Malaysian/Dutch/Indonesian/Korean
• 20. Factory setting password: 1234
• 21. Shell size: 172mm x 212mm
• RCA port parameters
• 1. Audio output: 2 channels (left channel + right channel)
• 2. Video output: 1 channel
• 3. Video input: 1 channel
• 4. Reversing video input: 1 channel
• 5. Subwoofer output: 1 channel
• Format parameters
• 1. Audio format: MP3/WMA/WAV/APE/FLAC/AAC/OGG/RM
• 2. Video format: MPEG/AVI/RM/FLV/ASF/WMV/MP4/MKV/OGM/TS/DivX/RMVB/VOB
• 3. Image format: JPG/BMP/PNG/JPEG/GIF
• Packing list:
• - Host
• - GPS antenna
• - 20P power cord
• - RCA cable
• - Instruction manual
• - USB1
• - USB2
