Product Features

• 1. Receiver: L1 type, C/A code
• 2. Capture channel: 51
• 3. Tracking channel: 14
• 4. Update frequency: 10 Hz (MAX)
• 5. Display image rate: 128x64
• 6. Backlight type: blue
• 7. Memory: 512KB
• 8. Buttons: 3 buttons
• 9. Accuracy: positioning, 10 meters (supports differential correction system area 2 meters)
• 10. Speed: 0.1 meters per second
• 11. Initial positioning time: about 5 seconds for hot start, about 40 seconds for warm start, and about 2 minutes for cold start
• 12. Sensitivity: -161dbm tracking, -157dbm recapture, -148dbm capture
• 13. Data protocol: NMA-0183 v3.01
• 14. Power supply voltage: USB DC 5V/3.7V
• 15. Power supply: 390 mA built-in lithium battery
• 16. Interface: USB
• 17. Operating time: about 6 hours
• 18. Power consumption: capture about 70 mA, continuous tracking about 30 mA
• 19. Ambient temperature: working -20 degrees ~ +55 degrees, storage -30 degrees ~ +55 degrees
• 20. Environmental humidity: 80 percent non-condensing humidity (MAX)
• 21. Ultra small size, easy to carry
• 22. Handheld GPS mini receiver, with latitude and longitude coordinate indication and guidance, global time zone time, distance, mileage, speed and other data collection, calculation and display functions
• 23. During the navigation process, provide clear travel data such as current location geographic coordinates, target direction and distance, satellite time, travel speed, etc.
• 24. Appearance size: 65x52x21 mm
• 25. Weight: 39.6g
