Product Features

• Basic functions
• 1. Radio (FM AM)
• 2. Read USB disk, TF card (audio/video/picture)
• 3. Rear audio input function
• 4. Bluetooth function
• 5. Subwoofer output
• 6. Reversing rear view function (camera not included)
• 7. Video input and output function
• 8. Original car steering wheel learning function
• 9. Android recorder can be installed
• 10. WIFI Internet access
• 11. GPS navigation
• 12. Recorder function
• 13. APP can be installed
• 14. RDS function, real-time traffic radio can be received
• 15. External microphone function (microphone not included)
• 16. USB charging function (2.1A)
• 17. Wired and wireless for Apple CARPLAY and Android AUTO function
• 18. DAB function (install customer APP)
• 19. Colorful lights
• Basic parameters
• 1. Applicable Volkswagen Passat
• 2. System: Android 12
• 3. Software solution: Jinganchi private board
• 4. Radio frequency: FM 87.5~108.0MHz 522~1620KHz (switchable Europe, Eastern Europe, North America, South America, Africa, Australia, Japan regional radio frequency)
• 5. Radio chip: 4745
• 6. Amplifier chip: YD7388
• 7. Output power: 60Wx4
• 8. Working voltage: 12~14.4V
• 9. Bluetooth version: version 5.1 (default name: CAR BT)
• 10. WIFI frequency: 2.4GHz
• 11. GPS signal: Beidou/GPS/GLONASS
• 12. Support reversing image, video warning, steering wheel control (button learning), video output, offline map, driving recorder (USB signal input), GPS navigation, rear USB (USB2.0 X 2) 5V USB port (rear USB charging port, 2.1A), TEST USB port (alcohol tester input port), external microphone port, TF card, reset button
• 13. Chinese/Traditional Chinese/English/Russian/Greek/Polish/Turkish/Arabic/Persian/Romanian/French/Hungarian/Italian/Thai/German/Ukrainian/Spanish/Portuguese/Czech/Vietnamese/Japanese/Malaysian/Dutch/Indonesian/Korean
• 14. Factory setting password: 1234
• 15. Installation size: 180x114mm
• 16. Shell size: 188x116mm
• 17. Host depth: 75mm
• Performance parameters
• 1. CPU: A7 1.1GHz x 4
• 2. Running memory: 1G (DDR3)
• 3. Storage memory: 16G
• 4. Display resolution: 1024x600
• 5. Screen size: 7 inches
• RCA port parameters
• 1. Audio output: 2 channels (left channel + right channel)
• 2. Subwoofer output: 1 channel
• 3. Video output: 1 channel
• 4. Audio input: 2 channels (left channel + right channel)
• 5. Video input: 1 channel
• 6. Reversing video input: 1 channel
• Format parameters
• 1. Audio format: MP3/WMA/WAV/APE/FLAC/AAC/OGG/RM
• 2. Video format: MPEG/AVI/RM/FLV/ASF/WMV/MP4/MKV/OGM/TS/DivX/RMVB/VOB
• 3. Image format: JPG/BMP/PNG/JPEG/GIF
• Packing list:
• - Host
• - GPS antenna
• - Dedicated power cord x2
• - USB cable x2
• - Instruction manual
• - Chili antenna
• - Disassembly key x4
